Energy Stackable Lithium Battery(HV) 5-20kwh

Energy Stackable Lithium Battery(HV) 5-20kwh
Energy Stackable Lithium Battery(HV) 5-20kwh
Energy Stackable Lithium Battery(HV) 5-20kwh

Energy Stackable Lithium Battery(HV) 5-20kwh

Stackable Lithium Battery (HV)

Product Datasheet

Energy Stackable Lithium Battery(HV) 5-20kwh





Parameters



Model

SNE-ES

HV5.0

SNE-ES

HV7.5

SNE-ES

HV10.0

SNE-ES

HV12.5

SNE-ES

HV15.0

SNE-ES

HV17.5

SNE-ES

HV20.0

Nominal Energy (KWh)

5.12

7.68

10.24

12.8

15.36

17.92

20.48

Usable Energy (KWh)

4.61

6.91

9.22

11.52

13.82

16.13

18.43

Nominal Voltage (V)

102.4

153.6

204.8

256

307.2

358.4

409.6

Recommend Charge/Discharge Current(A)

30/30

Max Charge/Discharge Current (A)

50/50

Round-Trip Efficiency

≥97.5%

Communication

CAN,RJ45

Charge Temperature ()

0-50

Discharge Temperature (°C)

-20-55

Weight (Kg)

69

94

119

144

169

194

219

Dimension (W*H*D mm)

540*520*280

540*670*280

540*820*280

540*970*280

540*1120*280

540*1270*280

540*1420*280

Module Number

2

3

4

5

6

7

8

Enclosure Protection Rating

IP54

Recommend DOD

80%

Cycles Life

10.000

Design Life

20+ Years (25°C@77°F)

Humidity

5%-95%

Altitude(m)

<2.000

Installation

Stackable

Warranty

10 Years

Safety Standard

UL1973/IEC62619/UN38.3
