EET - 200 has all the functions of large
container energy storage, including peak shaving and valley filling, remote dispatching, off grid and grid connection, reactive power compensation, countercurrent prevention, demand control, and Microgrid management.
Energy Battery EET-200(ESS)
IP67 Battery Pack Design
IP54 Energy Storage Cabinet Design
Support Multi System Parallel Working
Product Description
EET – 200 is a small industrial and commercial power storage system, which is equipped
with a leading self-developed
battery management system and energy management system.
Through excellent heat dissipation design and outdoor waterproof design, the system can work
normally and
stably in a variety of complex environments.
EET-200 System Parameter
|
AC Side |
General Information |
Parameters |
Remarks |
|
Voltage Range (V/Hz) |
AC400土15% 50/60 |
|
|
|
Maximum Current(A) |
167 |
|
|
|
THDI |
<3% |
Total Harmonic Distortion of Current |
|
|
Power Factor |
-0.9 to 0.9 |
Adjustable |
|
|
Rated Charging and Discharging Power (KW) |
100 |
|
|
|
Maximum Charging and Discharging Power (KW) |
110 |
|
|
|
Cell Type (Ah) |
LFP-280 |
|
|
|
Electric Config |
1P234S |
|
|
|
Rated Voltage (V) |
748.8 |
|
|
|
Battery Side |
Rated Capacity (KWh) |
210 |
|
|
DOD |
0~95% |
|
|
|
Cycle Life |
6000 |
Cycle 90% Charging and Discharging, Attenuation to 80% soC. |
|
|
Efficiency |
Maximum Energy Efficiency of the System |
>86% |
|
|
Peak Cutting and Valley Filling |
Have |
|
|
|
Function |
Remote Scheduling |
Have |
|
|
Size (mm) |
1300x1300x2100 |
Width x Depth x Height |
|
|
Weight (kg) |
2500 |
|
|
|
Operating Temperature (°C) |
-20~50 |
|
|
|
Relative Humidity (RH) |
0~95% |
|
|
|
Basic Parameters |
Maximum Working Altitude (m) |
2000 |
100% AC Output |
|
protection Grade |
IP54 |
|
|
|
Cooling Mode |
Liquid Cooling |
|
|
|
Display |
Upper Computer |
|
|
|
Communication Mode |
TCP/IP |
|
